What is SHR?
SHR (Advanced Florescence Technology) utilizes the photons from all wavelengths, including the wavelengths that are filtered out of the spectrum. The increased energy leads to enhanced clinical results, less pain and downtime, while extending the lifetime of the handpiece.
What is IPL with SHR?
Intense Pulsed Light with SHR technology is a treatment breakthrough that can correct a variety of benign skin conditions such as facial skin imperfections, the signs of aging, birthmarks, unwanted hair, unsightly small veins and other blemishes. It offers a safe, non-invasive solution that can be tailored to your individual condition and skin type, providing superior cosmetic results and outstanding satisfaction.
SHR Pulse Shape
SHR technology enables continuous square-shaped pulsing with moderate peak power throughout the entire pulse, for efficacious, safe results. The fluence of an SHR pulse is equally distributed, delivering optimal energy within a short, continuous pulse duration.
Technology Advantages
Machine Advantages
Display Advantage
Parameter
Function |
SHR |
IPL |
Wavelength |
430nm/480nm/530nm/590nm/640-1200nm (560/690/755-1200nm for option) |
|
Handpiece number |
1 handpiece with 5 filters |
|
Spot size |
15mm*50mm(8mm*40mm option) |
|
Energy |
10-50J/CM2 |
1-50 J/CM2 |
Pulse width |
1-5ms |
1-20ms |
Pulse repetition rate |
1-3HZ |
|
Pulse number |
|
1-5 |
Pulse delay |
|
1-50ms |
Shot period |
|
1-4s |
Cooling |
Continuous contact cooling |
|
Continuous shooting time |
Up to 40min |
|
Skin cooling |
-4°c-10°c |
|
Display |
8 inch color touch screen |
|
Output power |
2000W |
|
Lamp life |
200,000 shoots |
100,000 shoots |
Capacitance |
44000 uf |
